The principle of induction tomography. The tube of magnetic lines as analog of beam in classic tomography


The coil system of induction tomograph. 1 - inductors and detectors, 2 - screen


Experimental measuring system for magnetic induction tomography with 16 inductors and detectors. The bottle filled with saline solution inside the system is used as test object


Image reconstructed from the data measured with the system. The dark spot corresponds to the test object (plastic bottle 10 cm in diameter filled with 5% saline). The outward circle is drawn with diameter on which the coils are placed


Configuration of the complex phantom (percentage is the saline concentrations)


Reconstructed image (reference data set used for reconstruction was measured with the large tank without inner cylinders)


Initial conductivity distribution, which was used for simulation of measurements. Lightest areas correspond to highest resistivity, the spots approximate some organs inside human chest (1 - muscles, 2 - spine, 3 - lungs, 4 - heart)


Image reconstructed from the simulated results of measurement for 32-coil magnetic induction tomography system


Human head cross-section: one of the first in-vivo images. Two bright spots in the central part may be identified as ventricles of the brain filled with CSF.
